Product Features
1. Two operation modes as,
a. Lubrication： The lubricator runs via lubrication time after power-on.
b. Intermittence： The lubricator runs via intermittent time after power-on.
2. Lubrication time and intermittent time are adjustable.
3. The float switch alarms and output signal when the oil level is low.
4. The over temperature/load protector is attached to protect the motor.
5. The function of fixed pressure for the pressure relief valve can prolong the system life
6. The indicator on the panel can display the operation of the lubricator.
7. “Feed” key can force the lubricator to function.
มาเป็นคนแรกที่วิจารณ์ “YET-R-3L”
| Model | YET-R1 |
| Voltage (Single Phase) | 110V or 220V |
| Consumption Power (W) | 100 |
| Capacity of Terminal Output (A) | 3 |
| Lubrication time (second) | 1-180 |
| Intermittent Time (minute) | 1-180 |
| Output Bore | Ø4 or Ø6 |
| Max. Output Pressure Mpa (kgf/cm2) | 0.5 (5) |
| Output Volume (cc/mm) | 200 |
| Float Switch | O |
| Pressure Release device | X |
| เพชเชอเกจ | O |
| Alarm Beeper | O |
| Tank Capacity (L) | 2 / 3 / 4(Metal Tank) |
| Weight (kg) | 2.6 / 2.9 / 3.6 |
Note： Because of continuous improvements, above specifications are subject to change without prior notice.
