คำอธิบาย
Product Features
1. The motor is of long-time operation.
2. The pressure release device is included.
3. The power indicator displays the operation of the lubricator.
4. “Feed” key can force the lubrication to function. (cooperate with PLC control syste
1. Three operation modes as,
a. Lubrication : the lubricator runs via lubrication time after the power is on.
b. Intermittence : the lubricator runs via intermittent time after the power is on.
c. Memory : the lubricator runs via the previous set after the power is on.
2. Lubrication and intermittent time can be adjusted.
3. The float switch alarms and output signal when the oil level is low.
4. The over temperature/load protector is attached to protect the motor.
5. The function of fixed pressure for the pressure relief valve can prolong the system life.
6. Lubrication time (second/minute) and intermittent time (second/minute/hour/cycle) are adjustable.
7. The indicator on the panel can display the operation of the lubricator.
8. The intermittent period can be adjusted via the machine’s action cycles.
9. “RES” key can force the lubricator to function.m).
มาเป็นคนแรกที่วิจารณ์ “YET-A-4L”
| Model | YET-A1 | YET-A1P1 |
| Voltage (Single Phase) | 110V or 220V | 110V or 220V |
| Consumption Power (W) | 100 | 100 |
| Capacity of Terminal Output | DC/AC 250V 3A | DC/AC 250V 3A |
| Lubrication time (second/minute) | 1-999 | 1-999 |
| Intermittent Time (second/minute/hour/cycle) | 1-999 | 1-999 |
| Output Bore | Ø4 or Ø6 | Ø4 or Ø6 |
| Max. Output Pressure Mpa (kgf/cm2) | 0.7 (7) | 0.7 (7) |
| Output Volume (cc/mm) | 200 | 200 |
| Pressure Release device | X | X |
| Float Switch | O | O |
| Pressure Switch (kgf/cm2) | X | 2.5-1.9 |
| เพชเชอเกจ | O | O |
| Alarm Beeper | O | O |
| Tank Capacity (L) | 2 / 3 / 4(Metal Tank) | |
| Weight (kg) | 2.7 / 2.9 / 3.7 | |
